OUR PROJECT

‍Client : PT ENERGASINDO HEKSA KARYA (EHK)
Year : 2023
Location : Siak, Riau
‍
Project Overview
This distribution facility includes a pipeline approximately 12 km long, stretching from Perawang Station to IKPP Station. This pipeline passes through three different areas, namely the TGI, ARARA, and IKPP regions. The natural gas supplied comes from the Grissik - Duri Transmission Pipeline owned by PT Transport Gas Indonesia, which will be connected to the IKPP Station through two metering stations, one substation, and a pipeline system.

The project includes the construction of the EHK Perawang Metering Station, Perawang Substation, and IKPP Metering Station. The EHK Perawang Metering Station serves as the starting point, with the Perawang Substation next to it, and ending at the IKPP Metering Station.

Scope of Work :

• Desain teknis, pembuatan dokumen EDL, dan penyusunan gambar konstruksi (AFC).
• Pembuatan dokumen inspeksi dan rencana pengujian (ITP).
• Penyelesaian dokumen untuk handover, termasuk As-Built Drawings.

‍Procurement

• Pengadaan material dan peralatan (prioritas untuk long lead items).
• Koordinasi dengan vendor dan subkontraktor untuk memastikan kualitas dan jadwal pengiriman sesuai target.
• Pengawasan logistik dan proses customs clearance.

Civil Works

• Pembuatan pondasi, retaining wall, shelter, water pond, dan area parkir.

Mechanical & Piping

• Instalasi peralatan mekanis :some text
  • Fire Water Pump, Gas Filter Coalescer, Condensate Tank.
  • Hot Tap dan Spool Service di area pipa.
• Pengelasan pipa, pengujian non-destruktif (NDT), dan hydro test.

Electrical & Instrumentation

• Instalasi panel listrik, lightning protection, dan sistem kontrol.
• Pemasangan peralatan seperti Diesel Engine Switch Gear, CCTV, PAGA, dan flow control system.
• Sistem komunikasi dan instrumentasi untuk metering dan analisis gas.

Pipeline Construction

• Ekskavasi, pengelasan, boring untuk crossing, NDT, dan Hydro test.
• Tie-in Perawang Station, Sub-Station, dan Orifice Metering Station di IKPP Plant.

Commissioning

• Pre-commissioning (hydrotest, dewatering, drying, dan N2 purging).
• Penerbitan sertifikat COI (Certificate of Inspection) dan PLO (Persetujuan Layak Operasi).

Years : 2003
Location : Panaran, Batam
Client : PT. Perusahaan Gas Negara Tbk SBU III - SumBagUt

Scope Of Work : Procurement and Installation of Offtake Ultrasonic Gas Metering Station.
Scope Of Supply :
- USM
- Pressure Control Valve,
- Pressure Regulating Valve,
- Analyzing System,
- Sludge Catcher,
- Fire Suppression (FM-200),
- and Odorizer System.

‍

Year           : 2021

Location  :  Riau, Sumatera

Client        :  PT. TRANSPORTASI GAS INDONESIA

‍

Year           : 2020

Location  : Koto Gasib, Riau, Sumatera

Client        :  PT. TRANSPORTASI GAS INDONESIA

Scope of Work :  EPCC For DPMF PLTGU Riau Integrated with Koto Gasib Metering

Product Installed :

- Metering USM Package including with Gas Analyzer

- Valve, Control Valve, Shut Down Valve

- Gas Filter Package

- Field Instrument

- PLC,CCTV

- Lightning Protection and Grounding System

- SCADA

- Fire and Gas System

‍

‍

‍

‍

Year           : 2022

Location  : Cilacap

Client         : PT. Pertamina Internasional RU IV Cilacap

Scope of work :

  - Pipeline underground
  - Pipeline above ground with pipe sleeper
  - Crossing Road
  - Tie in pipe

‍

Year           : 2019

Location  : Jirak, Sumatera

Client         : PT. Pertamina EP

Scope of work :

EPC EOR JIRAK WATERFLOOD PROJECT, consist of :

1.   Gross Handling Unit :

      - Skimming Tank

      - FWKO (Free Water Knock Out)

2.   Water Treatment and Injection Plant :

      - Produced and Treated Tanks

      - Pretreatment System

      - Nutshell Feed Pump

      - Nutshell Filtration System

      - Induced Gas Floatation System

      - Decanter Tank

      - CPI Tank

      - Chemical Injection System

      - Water Injection Pump

3.   Power Generating System :

      - 4×75MW Gas Engine Generator System

      - MV and LV Switchgear

      - Emergency Diese Engine Generator

      - UPS System

4.   Utility System :

      - Instrument Air and Utility Air System

      - Utility Water System

5.   Supporting System :

      - SCADA, PCS, SIS, ESD System

      - FM 200, Watermist, Hydrant and Fire Alarm System

      - Telecommunication System

      - Lighting Indoor and Outdoor System

      - Grounding and Lightning Protection

      - Civil Control Building, Sub Station Building, Open shelter and Dormitory

6.   Interfacing with Existing Facilities :

      - Electrical Power System

      - Piping System

      - Instrumentation System

Product Installed :

- Demulsifier

- Filtration System

- Storage Tanks

- Scada System

- Electrical, Instrument , Control System

- Valve, Fittings

‍

Year          : 2018

Location : Bontang, Kalimantan

Client       : PT. Badak LNG

Scope of work : Engineering Procurement and Construction 3 MW Solar Power Plant, includes :

(i) Engineering

(ii) Procurement

(iii) Construction

(iv) Technical Examination & Testing

(v) Pre-Commissioning

(vi) Commissioning Phase

(vii) Installation Acceptance

(viii) Final Acceptace

(ix) Operation and Maintenance Training

(x) Land preparation and licensing

Product Installed :

- Solar Cell, Inverter

- DC Combiner & AC Combiner

- Low Voltage Panel

- Transformator

- Medium Voltage Panel

- Kiosk Panel

- SCADA System

- CCTV System

‍

Year             : 2018

Location     : Duri, Sumatera

Client           : TGI

Scope of work : EPCC Metering Station with 255 MMSCFD Design for the purposes of gas distribution in Duri and Dumai Area.

Installed Product :

          Custody USM Metering

           Analyzer

           Pressure Control Valve

           Gas Chromatograph

           Pressure Transmitter and Temperature Transmitter

    Sampling Probe

    Flow Computer

           HMI,PLC,PDB,UPS

           Gas Engine Generator

    Diesel Engine Generator

           Fire and Gas system

           Lightning Protection System

           Lighting (Indoor and Outdoor)

           SCADA

           Limit Switch

‍

Year         : 2017

Location : Grissik,Duri Sumatera

Client      : Conoco Phillips

Scope of work : EPC Grissik – Duri USM Upgrade Project

Installed Product :

      - Custody USM Metering

      - Valve Gas Pipeline

      - Instrumentation

      - Meter Shelter

‍

Year        :  2016

Location : Banggai, Sulawesi

Client      : Pertamina JOB Tomori

‍

Scope of work :

The operating Joint Operating Body Pertamina –  Medco E&P (JOB PMTS) will be

developing the Senoro gas field, located onshore near the coast of Senoro-Toili

Block on the eastern arm of Sulawesi Island, Indonesia. Senoro Central

Processing Plant through common 30” main gas pipeline will deliver 55 MMscfd of

sales gas to Ammonia Plant while others to existingLNG Plant.

To be able to deliver sales gas for Ammonia Plant,  PAU Gas Metering Station

developed to measure total sales gas while existingGas Metering Station already

dedicated to existing Buyer. The facility for PAU Gas Metering Station project will

consist Sales Gas Separator SNO-V-5301, 2 x 100% Sales Gas Filter SNO-F-5302A/B, 2 x 100% Main Ultrasonic Metering, Emergency Diesel Generator, and Instrument/Utility Air System.

Product Installed :

- USM

- Gas Chromatograph

- H2S Analyzer

- H20 Analyzer

- Hydrocarbon Dupoint

- HVAC

‍

Year           : 2017, 2018, 2019

Location : Sumatera,Sulawesi

Client        : Kementerian ESDM

Scope of work : Procurement and installation of converter kit equipment

Scope of Supply :

- Gas fuel tank Type 4

- Distribution Pipe

- Regulator / Reducer

- Injection Rail

- Cylinder Valve

- Isolation Valve

- Non return Valve

- Charging Connection

- Automatic breaker

- Electronic gas fuel volume indicator

- Electronic and cable control devices

‍

Year        : 2011, 2012, 2014, 2018

Location : Bekasi, Cirebon, Lhoksumawe,

Semarang, Pasuruan, Probolinggo, Serang, Bogor.

Client      : Kementerian Energi dan Sumber Daya Mineral (ESDM)

‍

Scope of work : EPC, Gas Distribution Construction and Gas Pipeline to residential

Scope of Supply :

- Gas Meter Diaphragm

- Gas Regulator

- Flowmeter

- Valve ( Ball, Butterfly, Check)

- Turbine Meter

- Gas Filter

- Expanded Metal Join

‍

Year           : 2014

Location : Batam, Riau

Client        : TGI

Scope of work :

For restore the reliability of the meter system at Panaran station and increase it to accuracy of the meter system by upgrading including Dry and Wet Calibration Meter streams A and B to replace the existing stream meter on Panaran station.

Product Installed :

- USM

- Air Compressor

- Pipe Spool 8”

- Pressure Transmitter

- Temperature Transmitter

- Temperature Detector

- Thermowell

- Drainline Valve

‍

Year        : 2018
Location : Grissik, South Sumatra, Indonesia
Client      : ConocoPhillips (Grissik) Ltd

‍
Scope of Work    : Engineering, Procurement and  Construction (EPC) Grissik – SSWJ Ultrasonic Metering (USM) Wet Calibration Project
Scope of Supply : Custody USM metering, Valve gas pipeline, Instrumentation and  Meter shelter

‍

Year         : 2014
Location  : Ngoro, East Java
Client       : PT. PGN

‍
Scope of Work    : EPC Off Take Station included Gas Metering Skid, Fire & Gas Detection System, Hydrant System and Site Office.

‍
Scope of Supply :
-Gas Metering & Pressure Regulator completed with Orifice Meters, Flowcomputer & Chart Recoder

‍

Year        : 2013
Location : Balikpapan, Sidoarjo, Jakarta
Client      : ESDM – Pertamina Gas Directorate

‍
Scope of Work    : EPC SPBG Station Completed with MRS, Gas Compressor, Gas Bottles and Gas Dispensing Units
Scope of Supply :
• Online Gas Metering
• Gas dryer
• Gas Scrubber & Filter
• Gas Dispenser Unit

‍

Year        : 2012
Location : Jambi
Client      : Pertamina UBEP Jambi

‍
Scope of Work    : B.O.T scheme 3 years contract, 2 mmscfd Gas Processing Facilities completed with maintenace & operator at Sungai Gelam
Scope of Supply : - Gas Filter- Separator Unit - Gas Metering Skid - Gas Dehydration Unit

‍

Year        : 2012
Location : Cilamaya, West Java
Client      : PT. Pertamina Hulu Energi ONWJ

‍
Scope of Work   : New Cilamaya Custody Transfer Gas Metering and Modification of Existing Facility to Supply Gas for Pertamina Refenery Unit VI Balongan
Scope of Supply :
- Custody Gas Transfer Metering completed with: Orifice Meters,Gas Chromatograph,  Flowcomp, and Chart Recorder.

‍

Year        : 2012
Location : Duri, Riau
Client      : PT. Indonesia Power

‍
Scope of work     : EPC, Gas Station Construction and Gas Pipeline to PLTG Duri
Scope of Supply  :
- Custody Metering
- Gas Filter Unit
- USM
- Gas Pipeline

‍

Year        : 2008

Location : Muara Tawar, Bekasi West Java

Client      : PLN Muara Tawar

‍

Scope of work    : Design and project Implementation (Supply, Installation, Calibration, Start-up and Commissioning) Metering System for PLN

Scope of supply : Custody Metering completed with: Gas Filter Unit, Orifice Meter Skid

‍
